Maxx15 Ultra Thin Lighting

Ultra Thin Track Lighting Magnetic

2 Smalle magnetische track 19mm breed Compacte lampvoet 15.5mm breed

3 ULTRA THIN TRACK LIGHTING Maxx15 ULTRA THIN TRACK LIGHTING Innovative Ultra Thin Track Lighting Enjoy the new design concept of pure minimalism and ultra-thin tracks by Maxx15. The fine appearance hides a precise internal structure, using exquisite innovative technology, with simple installation steps and great interior effect, making each space more elegant with Maxx15. Geniet van puur minimalisme met de ultradunne track lighting van Maxx15. Het fijne uiterlijk herbergt een uitgekiende interne structuur en maakt gebruik van de nieuwste innovatieve 48v verlichtingstechnologie. Kies uit een ruim aanbod van spots, hanglampen en lineaire verlichting. voor een elegante prachtige design verlichting, genaamd Maxx15. Le concept de design pur minimalisme et ultra fin de Maxx15, l’apparence délicate cache la structure interne précise, l’apparence simple, la belle technologie innovante, installation facile, rendant tout intérieur plus élégant avec le magnifique éclairage design d’Interluxx Maxx15. Maxx15 Magnetic

4

5 ULTRA THIN TRACK LIGHTING ULTRA THIN MAGNETIC LIGHTING TRACK SYSTEM

6

7 ULTRA THIN TRACK LIGHTING Four kinds of Track Rail Five modes of installation Door de minimale hoogte van slechts 13,5 mm ultra-dunne mini-magneetrail, kan de installatie zowel als opbouw, maar ook zeer elegant inbouwen in muur of plafond. Met horizontale of verticale hoekverbindingen om te voldoen aan de moderne eisen van modellering en state-of-the-art interieurontwerp. The height of only 13.5mm slim mini magnet track rail, has the abundant installation can be integrated into the wall or ceiling, each equipped with horizontal or vertical corner connectors to meet the requirements of modelling and interior design.

8 Track Standaard lengte’s / Track Standard Lenghts

9 ULTRA THIN TRACK LIGHTING Opbouw | Surface mounting | Apparent Inbouw | Recessed mounting | Encastré OPBOUW / SURFACE INBOUW PLAASTER / RECESSED INBOUW GYPROC / RECESSED

10 Controlling & Dimming

11 ULTRA THIN TRACK LIGHTING A B C D MT15-SSS Surface Mount Black CN15-SSSHO Horizontal Angle Of Surface Mount Black AS15-JT04 Horizontal Angle Energized connector Black AS15-JT03 Flexible Energized connector Black CN15-SSSIN Inner corner Of Surface Mount Black E B F D MT15-SPS Pre-buried Mount Black CN15-SPSHO Horizontal Corner Of Pre-buried Track Black CN15-SPSIN Inner Corner Of Pre-buried Track Black AS15-JT04 Horizontal Angle Energized connector Black AS15-JT03 Flexible Energized connector Black B D E F MT15-STS Recessed Mount Black AS15-JT04 Horizontal Angle Energized connector Black AS15-JT03 Flexible Energized connector Black CN15-SPSHO Horizontal Corner Of recessed track Black CN15-SPSIN Inner Corner Of recessed track Black The Splicing Method Recessed Track Is The Same As Pre-buried Track,when Splicing, The Corresponding Accessories Can Be Steated According To Their Marks. 11

12

13 ULTRA THIN TRACK LIGHTING Ultra Mini Magnet Track System Lamp Modules

14 Luminaires / Lights Magnetic Track System Wandlampen Hanglampen On track lights Minispots Twin spots Vouwbare armaturen Grille lights - smalle lichthoek Floodlights - brede lichthoek

15 ULTRA THIN TRACK LIGHTING

16 Grille Light - Linear Light M15-GL06 Grille Light - Linear Light M15-GL12 Anti Glare Grille Light - Linear Light M15-CG06 Anti Glare Grille Light - Linear Light M15-CG12

17 ULTRA THIN TRACK LIGHTING Foldable Grille Light - Linear Light M15-AG08 FoldableGrille Light - Linear Light M15-AG16 Grille Light High - Linear Light M15-G008 Grille Light High - Linear Light M15-G016

18 Spotlight M15-SP22 Spotlight M15-SP32 Spotlight M15-SP72

19 ULTRA THIN TRACK LIGHTING Circular Atmosphere Light ROUND M15-RL01 Square Atmosphere Light SQUARE M15-RL01 Global Pendant Light / Handlamp GLOBE M15-SU01 Global Pendant Light CONE M15-SU04 Global Pendant Light BALLO BLACK M15-SU02 / SU03

20 Features Soft Light Optical Diffuser Strong Magnetic Click-in Advanced Optical System Anti-Glare Optical System Sdcm>3 Superior Lighting

21 ULTRA THIN TRACK LIGHTING Crystal Diamond Appearance, pure and transparent improve light efficiency Advanced Optical System Stainless Steel Damping Shaft Opal Glass Lamp Shade Soft Glazed Glas Cover

22

23 ULTRA THIN TRACK LIGHTING

24

25 ULTRA THIN TRACK LIGHTING M15-SU03 BALLO BLACK Product Codes MT553200 BALLO BLACK 6W 2700k 352Lm 360° MT553202 BALLO BLACK 6W 3000k 352Lm 360°

26

27 ULTRA THIN TRACK LIGHTING M15-LG GLASS LIGHT Product Codes MT561100 GLASS Ø8cm 3W 2700k 240Lm MT561102 GLASS Ø8cm 3W 3000k 240Lm

28 De RL ATMOSPHERE is een armatuur met een subtiele sfeer, verkrijgbaar in vierkante en ronde uitvoering. Deze wandarmatuur straalt door de reflectietechniek de warmte en zachtheid uit met lichtkleurtemperatuur 2700K of 3000K. Een elegante èn discrete blikvanger voor elke ruimte. Ze kan gepersonaliseerd worden in verschillende afwerkingen en kleuren.

29 ULTRA THIN TRACK LIGHTING M15-RL01 & M15-RL02 ATMOSPHERE Product Codes MT562300 ROUND Ø21cm 5W 2700k 350Lm BLACK MT562310 ROUND Ø21cm 5W 3000k 350Lm BLACK MT562400 SQUARE 21.6x21.6cm 5W 2700k 350Lm BLACK MT562410 SQUARE 21.6x21.6cm 5W 3000k 350Lm BLACK

30 PERFECT CONNECTION BETWEEN THE TWO LAMP BODI ES M15-FL30 & M15-FL60 Product Codes MT150110 30cm 6W 160Lm MT150120 60cm 12W 320Lm PERFECTE VERBINDING TUSSEN TWEE OF MEERDERE ARMATUREN

31 ULTRA THIN TRACK LIGHTING MODEL VERMOGEN VOLTAGE CCT LICHTHOEK LICHTOPBRENGST KLEUR BEHUIZING CONTROL M15-FL30 M15-FL60 6 WAT T 12 WAT T 24VDC | 48VDC 2700k 3000k 4000k 110° 160 Lm 320 Lm BLACK ON/OFF

32

33 LINEAR LIGHTING DESIGN RECHTE L I JNEN

34 M15-GL06 & M15-GL12 Product Codes MT150210 30cm 6W 483Lm MT150230 60cm 12W 966Lm

35 ULTRA THIN TRACK LIGHTING MODEL VERMOGEN VOLTAGE CCT LICHTHOEK LICHTOPBRENGST KLEUR BEHUIZING CONTROL M15-GL06 M15-GL12 6 WAT T 12 WAT T 24VDC | 48VDC 2700k 3000k 4000k 36° 45° 483 Lm 966 Lm BLACK ON/OFF

36

37 ULTRA THIN TRACK LIGHTING

38 M15-CG Anti Glare Grille Light Product Codes MT150410 30cm 6W 408Lm MT150430 60cm 12W 821Lm

39 ULTRA THIN TRACK LIGHTING MODEL VERMOGEN VOLTAGE CCT LICHTHOEK LICHTOPBRENGST KLEUR BEHUIZING CONTROL M15-CG06 M15-CG12 6 WAT T 12 WAT T 24VDC | 48VDC 2700k 3000k 4000k 36° 45° 408 Lm 821 Lm BLACK ON/OFF

40 LINEAR DESIGN

41 ULTRA THIN TRACK LIGHTING R LIGHTING N STRAKKE L ICHTL I JNEN INBOUW / RECESSED

42 ULTRA THIN TRACK LIGHTING M15-GO Linear Grille Light Product Codes MT150510 30cm 8W 648Lm MT150530 60cm 16W 1232Lm

43 ULTRA THIN TRACK LIGHTING MODEL VERMOGEN VOLTAGE CCT LICHTHOEK LICHTOPBRENGST KLEUR BEHUIZING CONTROL M15-GO08 M15-GO16 12 WAT T 16 WAT T 24VDC | 48VDC 2700k 3000k 4000k 24° 40° 648 Lm 1232 Lm BLACK ON/OFF

44 Integrated Grille Diffuser The pursuit of perfection leaving no flaws Golden Ration Grid Distribution. Unique combination of 8 Lights & 16 Lights.

45 ULTRA THIN TRACK LIGHTING

46 M15-AG Adjustable Grille Light Product Codes MT150620 12cm 8W 648Lm MT150640 60cm 16W 1232Lm

47 ULTRA THIN TRACK LIGHTING MODEL VERMOGEN VOLTAGE CCT LICHTHOEK LICHTOPBRENGST KLEUR BEHUIZING CONTROL M15-AG08 M15-AG16 8 WAT T 16 WAT T 24VDC | 48VDC 2700k 3000k 4000k 24° 40° 648 Lm 1232 Lm BLACK ON/OFF

48

49 ULTRA THIN TRACK LIGHTING

50 M15-SP Spotlights Product Codes MT150910 3W 200Lm MT150920 5W 326Lm MT150930 7W 684Lm

51 ULTRA THIN TRACK LIGHTING MODEL VERMOGEN VOLTAGE CCT LICHTHOEK LICHTOPBRENGST KLEUR BEHUIZING CONTROL M15-SP03 M15-SP05 3 WAT T 7 WAT T 24VDC | 48VDC 2700k 3000k 4000k 24° 36° 200 Lm BLACK ON/OFF 5 WAT T M15-SP07 326 Lm 684 Lm

52 MODEL VERMOGEN VOLTAGE CCT LICHTHOEK LICHTOPBRENGST KLEUR BEHUIZING CONTROL M15-SP75 7 WAT T 48VDC 2700k 3000k 36° BLACK ON/OFF 684 Lm M15-SP is a series of spotlights of a new and innovative 48V system, available in different diameters: 20mm, 30 mm ,Luminaire housing of extruded aluminum, powder coated black or white from Akzo Nobel, specially engineered optics for clean and soft beam patterns, It comes with two different optics: 24° for spot, 40° for flood meeting accent and general lighting to enhance the interiors and architectural elements , there are also different options in control , it means it is compatible with most of controlling system including DALI, 0-10V, Triac, Zigbee, Bluetooth /Casambi etc.

53 ULTRA THIN TRACK LIGHTING Horizontale positie aanpasbaar met 355 graden rotatie. Verticaal richtbaar van 0° tot 90°.

54

55 ULTRA THIN TRACK LIGHTING M15-SU04 CONE Hanglamp Product Code MT552109 Cone Hanglamp 8W 2700k 36° 398Lm BLACK MT552110 Cone Hanglamp 8W 3000k 36° 398Lm BLACK MT552121 Cone Hanglamp 8W 2700k 36° 398Lm WHITE MT552122 Cone Hanglamp 8W 3000k 36° 398Lm WHITE MT552133 Cone Hanglamp 8W 2700k 36° 398Lm GOLD MT552135 Cone Hanglamp 8W 3000k 36° 398Lm GOLD MT552142 Cone Hanglamp 8W 2700k 36° 398Lm SILVER MT552144 Cone Hanglamp 8W 3000k 36° 398Lm SILVER NEW DESIGN 2024

56 ULTRA THIN TRACK LIGHTING

57 ULTRA THIN TRACK LIGHTING CONE Hanglampen 48V 8 Watt 400 Lumen Lichthoek 36° Warmwit 2700k & 3000k

58 DC48V Control Smartwatch Mobile I Pad Infrared Sensing Scene Panel Control Radar Sensors Power Supply Brown Cable: V+ Blue Cable : VGreen Cable: DIM+ Black Cable: DIMInt www.arcllux.com

59 ULTRA THIN TRACK LIGHTING DIMV+ DIM+ VAC220V TRACK + Connect Power Supply DC+ Connect Power Supply DC- No Connect No Connect telligent Control Wiring Mode 75

60 TEC.DRAWINGS 15 11.5 300 TEC.DRAWINGS 15 11.5 600 TEC.DRAWINGS 15 11.5 900 TEC.DRAWINGS 15 11.5 1200 TEC 11.5 300 TEC 11.5 600 TECHNISCHE TEKENINGEN & AFBEELDINGEN LINEAR LIGHTING

61 ULTRA THIN TRACK LIGHTING C.DRAWINGS 15 C.DRAWINGS 15 300 15 11.5 TEC.DRAWINGS 600 15 11.5 TEC.DRAWINGS 11. 1

62 TEC.DRAWINGS 150 50 11.2 φ22 15 TEC.D 150 11.2 15 50 φ22 TEC.DRAWINGS L150 11.2 58 φ32 15 TEC.D L150 15 11.2 58 φ32 TEC.DRAWINGS φ75 26 L150 15 11.2 TEC.DRAWINGS L150 11.2 58 φ42 15 TEC.D L150 15 11.2 58 φ42 TECHNISCHE TEKENINGEN & AFBEELDINGEN SPOTS SINGLE & TWIN

63 ULTRA THIN TRACK LIGHTING DRAWINGS 5 DRAWINGS TEC.DRAWINGS φ80 150 11.2 15 DRAWINGS

64 TEC.DRAWINGS TEC.DRAWINGS 110 35 16 35 16 220 435 16 35 1 TECHNISCHE TEKENINGEN & AFBEELDINGEN GRILLE / SMALLE LICHTHOEK

65 ULTRA THIN TRACK LIGHTING TEC.DRAWINGS TEC.DRAWINGS 110 87 16 87 220 16

66 TEC.DRAWINGS 19 15.5 13.5 TEC.DRAWINGS 13.5 15.5 50 19 ∅28 15.5 24.1 TEC.DRAWINGS 50 15.5 19 13.5 TECHNISCHE TEKENINGEN & AFBEELDINGEN TRACKS TEC.DRAWINGS 19 15.5 13.5 TEC.DRAWINGS 13.5 15.5 50 19 TEC.DRAWINGS ∅28 15.5 24.1 TEC.DRAWINGS 50 15.5 19 13.5 TRACKS VERBINDING- EN AANS

67 ULTRA THIN TRACK LIGHTING 76 15 11 16 3 TEC.DRAWINGS TEC.DRAWINGS TEC.DRAWINGS TEC.DRAWINGS TEC.DRAWINGS 94 11 TEC.DRAWINGS 42 42 13.5 19 TEC.DRAWINGS 45 45 Φ28 76 15 11 110 15 11 TEC.DRAWINGS 42 42 13.5 39 TEC.DRAWINGS 60 60 13.5 SLUITINGEN TEC.DRAWINGS TEC.DRAWINGS TEC.DRAWINGS 88 88 11 15 94 94 11 15 76 15 11 76 76 15 11

68 TECHNISCHE TEKENINGEN & AFBEELDINGEN TRACK HOEKVERBDINGEN TEC.DRAWINGS 42 42 13.5 19 TEC.DRAWINGS 45 45 Φ28 TEC.DRAWINGS 42 42 13.5 39 TEC.DRAWINGS 60 60 13.5

69 ULTRA THIN TRACK LIGHTING TEC.DRAWINGS 34.5 34.5 19 TEC.DRAWINGS 40 40 19 TEC.DRAWINGS 45 45 Φ28 TEC.DRAWINGS 45 45 Φ28 TEC.DRAWINGS 34.5 34.5 39 TEC.DRAWINGS 40 40 39 TEC.DRAWINGS 40 50 40 TEC.DRAWINGS 50 50 50

70 LOW VOLTAGE 48V RAILSYSTEM Ultra Thin Magnetic Track
